Netherlands Machine Centre LTD.

"ADI"AM mini LOPPER CE approved

The "ADI" AM Lopper is powerful, durable, light weight, quick action. Very slim, compact and smooth design, extra long reach from operating hands to cutter, good balance at hand.

OPTIONS:

· Non CE model.

· High pressure oil filter - installed between quick coupler and hydraulic "IN" line.

For more information click here: Portable Hydraulic power unit.



POWER REQUIREMENT

"ADI" mini LOPPERS AM MODEL

· Oil flow - 8-20 Litre/Min. (5 G.P.M) -Max Flow

· Max pressure 133 Bar (2000 P.S.I.).

· Oil - Hydraulic oil 10-30 SAE.

· Oil cleanliness - 25 Micron filtration.

· Max oil temp. - 60 degrees C.

Open/Closed hydraulic system - on tool (Please see our Hydraulic Power Unit).



INSTRUCTION BOOK & WARRANTY
Each tool includes complete Operation, Service and Parts Manual. We guarantee each tool to be free of defects in material and workmanship for one year from date of purchase (Warranty limitation listed in the instruction book).

"ADI" Loppers are powerful, highly productive, durable, easy to handle and operate: Steel cylinder and chrome plated rod.

Handle, operation, patented hydraulic system like on model AP.

Two 1/4 Flexible hydraulic hose swivel connections within handle for flexibility.

SPECIFICATIONS   Note: Figures indicated are rounded.

HEAD
DESIGN

LOPPERS
MODEL

OVERALL
LENGTH

WEIGHT

CUTTING
CAPACITY

MINI

AM

34 cm

0.76 kg.

30 mm
