"ADI" AP LOPPERS - Hydraulic Powered CE approved



ADI loppers are powerful, highly productive, durable, easy to handle and operate.

Three different cutter head designs interchangeable.

Five standard lengths.

Cutting head swivels on tool axis 360 degrees in relation to operation handle.

Sculptured insulated handle, finger trigger operated, full hand grip, safety trigger lock.

Considered insulated from model 185 and up.

Patented hydraulic system, eliminates springs, ensures oil free flow, less heat generated, simple and easy conversion to open/closed hydraulic system on tool.

Steel hydraulic cylinders, hard chrome rods for long life.

Hydraulic hose connections within handle for more flexibility.

Quality throughout for long trouble free operation.



OPTIONS:

Two hose 360 degrees swivel.

· Optional non CE models

· High pressure oil filter - installed between quick coupler and hydraulic "IN" line.

For more information click here: Portable Hydraulic power unit.



POWER REQUIREMENT

"ADI" LOPPERS AP MODELS

· Oil flow - 8-20 Litre/Min. (5 G.P.M) -Max Flow

· Max pressure 133 Bar (2000 P.S.I.).

· Oil - Hydraulic oil 10-30 SAE.

· Oil cleanliness - 25 Micron filtration.

· Max oil temp. - 60 degrees C.

Open/Closed hydraulic system - on tool (Please see our Hydraulic Power Unit).



INSTRUCTION BOOK & WARRANTY
Each tool includes complete Operation, Service and Parts Manual. We guarantee each tool to be free of defects in material and workmanship for one year from date of purchase (Warranty limitation listed in the instruction book).

SPECIFICATIONS      Note: Figures indicated are rounded.


HEAD
DESIGN

LOPPERS
MODEL

OVERALL
LENGTH

WEIGHT

CUTTING
CAPACITY

STANDARD

AP-110

112 cm

2.8 kg.

50 mm

AP-125

125 cm

3.1 kg.

AP-155

156 cm

3.4 g.

AP-185

186 cm

3.6 kg.

AP-215

217 cm

3.8 kg.

PARROT

APT-110

112 cm

2.8 kg.

50 mm

APT-125

125 cm

3 kg.

APT-155

156 cm

3.5 kg.

*APT-185

186 cm

3.7 kg.

*APT-215

217 cm

4 kg.

PALM

APP-110

112 cm

2.8 kg.

Note: Palm tree only
100 mm

APP-125

125 cm

3 kg.

APP-155

156 cm

3.6 kg.

*APP-185

186 cm

3.8 kg.

*APP-215

217 cm

4 kg.
