ADI ACS - Hydraulic Chain Saw

The ADI chain saw ACH is efficient, powerful, light weight, compact and safe to use, quiet and smooth.

OPTIONS:

· 16" chain saw bar.

Two hose 360 degrees swivel.

· Optional CE approval (European Standard)

· High pressure oil filter - installed between quick coupler and hydraulic "IN" line.

For more information click here: Portable Hydraulic power unit.



POWER REQUIREMENT

ADI Hydraulic Chain Saw

· Oil flow - 12-20 Litre/Min. (3 -5 G.P.M) -Max Flow

· Max pressure 133 Bar (2000 P.S.I.).

· Oil - Hydraulic oil 10-30 SAE.

· Oil cleanliness - 10 Micron filtration.

· Max oil temp. - 60 degrees C.

· Connecting threads 9/16 JIC 37 degrees.

Open/Closed hydraulic system - on tool (Please see our Hydraulic Power Unit).



INSTRUCTION BOOK & WARRANTY

Each tool includes complete Operation, Service and Parts Manual. We guarantee each tool to be free of defects in material and workmanship for one year from date of purchase (Warranty limitation listed in the instruction book).

· Powerful - up to 6.5 HP - high torque gear motor.

· Tough and light weight.

· Long reach compact design, easy access within tree.

· Electric insulated - Extension fibreglass non-conductive, flexible inner hydraulic hose "Synflex" non-conductive.

· Sculptured insulated handle, finger trigger operated, full hand grip, safety trigger lock.

· Hydraulic hose connection within handle for more flexibility.

· Cutting chain automatic oiler.

· Easy change open/close hydraulic system on tool.
